Mellanox ConnectX-4 Lx MCX4121A-ACAT Dual-Port 25GbE Network Adapter Card
รายละเอียดสินค้า:
| ชื่อแบรนด์: | Mellanox |
| หมายเลขรุ่น: | MCX4121A-ACAT |
| เอกสาร: | connectx-4-lx-en-card.pdf |
การชำระเงิน:
| จำนวนสั่งซื้อขั้นต่ำ: | 1 ชิ้น |
|---|---|
| ราคา: | Negotiate |
| รายละเอียดการบรรจุ: | กล่องด้านนอก |
| เวลาการส่งมอบ: | ขึ้นอยู่กับสินค้าคงคลัง |
| เงื่อนไขการชำระเงิน: | ที/ที |
| สามารถในการผลิต: | จัดหาโดย Project/Batch |
|
ข้อมูลรายละเอียด |
|||
| แอปพลิเคชัน: | เซิร์ฟเวอร์ | ประเภทอินเทอร์เฟซ:: | เครือข่าย |
|---|---|---|---|
| พอร์ต: | คู่ | ความเร็วสูงสุด: | 25gbe |
| ประเภทตัวเชื่อมต่อ: | SFP28 | พิมพ์: | แบบมีสาย |
| เงื่อนไข: | ใหม่และเป็นต้นฉบับ | แบบอย่าง: | MCX4121A-ACAT |
| ชื่อ: | การ์ดเครือข่าย Mellanox ConnectX-4 LX EN 25GBE Dual-Port SFP28 PCIE3.0 X8 Network Interface Card MCX | คำสำคัญ: | การ์ดเครือข่าย Mellanox |
| เน้น: | Mellanox ConnectX-4 Lx 25GbE network card,dual-port 25GbE network adapter,Nvidia ConnectX-4 Lx Ethernet card |
||
รายละเอียดสินค้า
NVIDIA ConnectX-4 Lx EN MCX4121A-ACAT Dual-Port 25GbE Network Adapter
Dual-port SFP28 25GbE Ethernet adapter card delivering 25/10/1GbE speeds, RDMA over Converged Ethernet (RoCE), and hardware-based virtualization offloads. Ideal for cloud, Web 2.0, database, AI, and storage platforms requiring high-bandwidth, low-latency connectivity.
Product Overview
The NVIDIA ConnectX-4 Lx EN MCX4121A-ACAT is a dual-port 25GbE Ethernet adapter card designed for data centers that demand high throughput, sub-microsecond latency, and efficient server utilization. Built on the proven ConnectX-4 Lx architecture, this adapter supports 25GbE, 10GbE, and 1GbE speeds, making it a flexible solution for enterprises upgrading from 10GbE to 25GbE infrastructure.
Key Features
- Dual-Port 25GbE: Two SFP28 ports supporting 25GbE, 10GbE, and 1GbE speeds with backward compatibility
- RDMA over Converged Ethernet (RoCE): Low-latency, high-performance RDMA services over Layer 2 and Layer 3 networks
- Hardware I/O Virtualization: SR-IOV supports up to 256 Virtual Functions (VFs) and 8 Physical Functions per port
- Overlay Network Offloads: Hardware encapsulation and de-encapsulation for VXLAN, NVGRE, and GENEVE
- CPU Offload Engines: TCP/UDP stateless offloads, LSO/LRO, checksum offload, RSS/TSS, and intelligent interrupt coalescence
- Host Management and UEFI: NC-SI over MCTP for BMC integration, remote boot over iSCSI, PXE, and UEFI support
Technical Specifications
| Category | Specification |
|---|---|
| Model | MCX4121A-ACAT |
| Form Factor | Low-profile PCIe add-in card (14.2cm x 6.9cm without bracket) |
| Ports | 2x SFP28 (25GbE / 10GbE / 1GbE) |
| Host Interface | PCIe 3.0 x8 (compatible with x16, x4, x2, x1) |
| Message Rate | 75 million packets per second (Mpps) |
| Latency | Sub-microsecond (typical) |
| Virtualization | SR-IOV: up to 256 Virtual Functions, 8 Physical Functions per port |
| RoCE Support | Yes – RDMA over Converged Ethernet (RoCE) |
| Overlay Offloads | VXLAN, NVGRE, GENEVE hardware encapsulation and de-encapsulation |
| Operating Temperature | 0°C to 55°C (typical) |
Key Performance Facts
Dual-port 25GbE SFP28
75 Mpps message rate
Sub-microsecond latency
RoCE supported
256 SR-IOV Virtual Functions
VXLAN/NVGRE offload
PCIe 3.0 x8
UEFI enabled
Typical Deployments
- Cloud and Web 2.0: High-density virtualization hosts requiring 25GbE connectivity
- Storage Servers: iSCSI, NVMe-oF, and SMB Direct over RoCE for high-performance access
- Database and Analytics: Low-latency RDMA accelerates distributed databases and big data frameworks
- AI and GPU Clusters: PeerDirect enables direct GPU-to-GPU communication
- 25GbE Data Center Migration: Seamless upgrade from 10GbE while maintaining backward compatibility
Compatibility
Operating Systems: RHEL/CentOS 7/8/9, Ubuntu 18.04+, Windows Server 2016/2019/2022, FreeBSD 12+, VMware ESXi 6.7/7.0/8.0, Citrix XenServer
Switches: NVIDIA Spectrum SN3000/SN3700 series, Cisco Nexus 3000/9000, Arista 7000 series, Juniper QFX series, any standards-based 25GbE/100GbE switch
Frequently Asked Questions
What is the difference between MCX4121A-ACAT and MCX4121A-XCAT?
MCX4121A-ACAT supports up to 25GbE speeds, while MCX4121A-XCAT supports up to 10GbE. Both are dual-port SFP28 adapters.
Does this card support RDMA over Ethernet?
Yes. The ConnectX-4 Lx EN supports RoCE (RDMA over Converged Ethernet) for low-latency memory access across the network.
Can I use this adapter with a PCIe 4.0 slot?
The card is PCIe 3.0 x8 but is backward compatible with PCIe 4.0 slots (operating at PCIe 3.0 speeds). No performance penalty.
